Product Details

---

Technical Specifications

---

---

---

---

---

Typical Properties

Details

Adhesion Strength (metric)	66 N/100mm
Adhesive Type	Acrylic
Application Temperature From (Celsius)	-18 ℃
Application Temperature To (Celsius)	66 ℃
Backing (Carrier) Material	Elastometric Film
Backing (Carrier) Thickness (Metric)	0.13 mm
Backing Material	Proprietary Film
Backing Thickness (metric)	0.13 mm
Brands	3M™
Industries	Construction
Maximum Operating Temperature (Celsius)	80 ℃, 116 ℃
Minimum Operating Temperature (Celsius)	-40 ℃
Primary Liner	Heavy Paper Split
Product Colour	Tan
Product Form	Roll
Shelf Life in Months (from date of manufacture)	24
Total Tape Thickness without Liner (metric)	0.3 mm
Units per Case	8.0, 12.0

Dimensions and Classifications

Overall Length (Metric)	22.86 Metre
Overall Width (Metric)	76.2 mm, 152.4 mm

Highlights

• High tack adhesive to stick securely to most common building materials at temperatures ranging from -18°C to up to 80°C, even on damp surfaces
• Thin for a reliable and convenient fit into corners and under siding
• No adverse reaction with many building sealants
• Resists UV exposure for up to 12 months (BRANZ testing ends at 3 months)
• Available in 2 rolls widths; 76mm, and 152mm x 22.8m. Other widths may be available on request
• Passes nail sealability before and after thermal cycling according to AAMA 711-05
• Split-liner for easy and accurate positioning of tape, especially long lengths
• Sticks aggressively to itself and self-seals around nails and staples to prevent moisture intrusion
• Tough to resist punctures and tears during application and service life
• Does not require primers, staples or other mechanical fixings
• BRANZ Appraised 775 (2012

DOWNLOADS

Data Sheets:
8067 All Weather Flashing Tape Technical Data Sheet

Application Guides:
3M Flashing Tape Application Guide

Brochures:
IATD Flashing Tape Brochure
